MT800Q

Overview
  • DSC_0814
  • DSC_0816
  • DSC_0842
  • DSC_0936副本
Specification

Printing

Print Method

Direct Line Thermal printing

Resolution

300 dpi

Print Speed

15 mm/s

Valid Printing Width

198 mm/s

Printing Density

Adjustable from level 1 to level 3

Printing Protocol

Bitmap printing

Interface

Standard

USB Type C(Support for USB charging) Bluetooth 3.0/4.0(Installed by Manufacturers)

Memory

Flsah

4 MB

Ram

8 MB

Media

Type

Thermal fax Paper, A4 copy paper

Width

210 mm

Ribbon

215mm(W)*14.5mm(Φ),14000mm(L)

Thickness

60~90 μm

Battery

Type

Rechargeable lithium battery

Voltage

7.4V

mAh

2000mAh

Sensors

Cover open detection, Paper out sensor, Paper positing detection, Paper offset detection, Ribbon detection and TPH temperature detection.

Electrical

Input

AC 100V ~ 240V, 50/61Hz

Output

DC 5V, 2A

Dimensions L*W*H

310.5×63.5×39.5 mm

Weight

Weight: 805g (with ribbon), 735.5g (without ribbon)

Reliability

TPH Life

50 km

Certificate

CCC/FCC/CE
